Brass Push-in Fittings

Features

  • High performance nickel-plated brass and imported SUS collet adds lifetime
  • Double O-ring design make sure the 100% sealing
  • High precision machine can make perpendicularity of Elbow and Tee connectors to 0.01
  • Universal thread type is available
  • Attractively priced all brass push-in fitting
  • Excellent resistance to high pressure and vacuum
  • Easy to install and remove
  • 100% leakage test

Product details

Additional information

Applicable Fluid Type

Air, Water(No Drinking Water), Vacuum

Working Pressure Range

-14~225 PSI; -0.99~15 Bar

Working Temperature Range

-4~160°F; -15~71℃

Vacuum Rating

to 28" Hg

Recmmanded Tubings

PA11, PA12, PA6, PE, PU, FEP, PFA

The all brass(metal) push-in fitting  is  high performing, extremely compact push-in full metal fitting, which designed as a wide range of applications. Such as automatic welding line, robotics, conveyer systems etc. It is particularly suited to media- compressed air, vacuum or some liquids compatible with the materials.

  • High precision machine can make perpendicularity of Elbow and Tee connectors to 0.01
  • Universal thread type is available
  • High performance nickel-plated brass and imported SUS collet adds lifetime
  • Attractively priced all brass push-in fitting
  • Excellent resistance to high pressure and vacuum
  • Easy to install and remove
  • 100% leakage test

Ideal bell offers all metal brass fittings ODs ranging from 4-12mm for metric size, 1/8-1/2 for inch size; Thread type R, G, NPT, Universal threads with range from 10/32 UNF, 1/8 to 1/2.Various shapes for choice:

Tube to thread connectors:

  • Straight stud fitting MPC, MPCF
  • Elbow swivel fittings MPL, MPLF
  • Branch Tee connectors MPT, MPTF
  • Run Tee fittings MPST
  • Bulkhead Female fittings MPMF

Tube to tube fittings:

  • Union Straight MPUC
  • Union Elbow Fittings MPUL
  • Union Tee Fittings MPUT
  • Equal Bulkhead fittings MPMM
  • Reduce Straight Fittings MPG

Others connectors:

  • Plug-in Reducer MPGJ
  • Plug MPP
